Benefits: • True dual-element construction allows sizing of 125% FLA for motor backup protection. • Superior overload and cycling capabilities. • Current limiting provides component short-circuit protection. Applications: • Recommended for AC power distribution system mains, feeders, and branch circuits. • Protection of motors and motor branch circuits. • Protection of transformers and other inductive loads. • All general-purpose applications including lighting

ECNR - 250Vac ECNR - (1-60A, 110-200A) 125Vdc; (225-600A) 250Vdc ECSR - 600Vac ECSR - (1-30A, 70-600A) 300Vdc (35-60A) 250Vdc Amp Rating: 1 - 600A Interrupting Rating: 200kA RMS Symmetrical Amps Current Limiting: RK5 Fuse Agency Approvals: UL Listed for US and Canada, Class RK5, Guide JDDZ, File E162363 Interrupting Rating: ECNR/ECSR 20kA DC
