Standby Generators

400A CSA Approved Service Entrance Rated Automatic Transfer Switch Quick shop
400A CSA Approved Service Entrance Rated Automatic Transfer Switch
eaton

400A CSA Approved Service Entrance Rated Automatic Transfer Switch

$660.00

Designed and Built in Canada, for Canada!

Eaton is pleased to announce the release of an expanded offering in our service entrance rated residential transfer switches for our Standby Generators! These NEW products add to Eaton’s comprehensive line of residential transfer switches.  With the electrical contractor and homeowner in mind, Eaton has designed and manufactured an ALL IN ONE solution to meet CEC requirements for complete home Standby Generator backup.

Introducing the industry first 400 amp service entrance rated automatic transfer switch, featuring LED position indicators, (EGSCA) advance load management, and engine start options.

View product
Air cooled standby generator 16KW Kit Quick shop
Air cooled standby generator 16KW Kit
Air cooled standby generator 16KW Kit
Air cooled standby generator 16KW Kit
Air cooled standby generator 16KW Kit
eaton

Air cooled standby generator 16KW Kit

$6,009.00 $6,299.00

Eaton's standby generators make it easy, affordable and worry-free, to supply reliable backup power for residential and light commercial applications. Whether you are home or away, they quietly protect your home and family, with an immediate, automatic, and reliable response to utility power failure, so power is never lost.

Kit Includes:

(1) 16 KW Eaton Generator

(1) Battery

(1) Battery & Oil Warmer

(1) 100 ATS with SE Rated Disconnect



Automatic Transfer Switches (ATS)

Eaton's Automatic Transfer Switches (ATS) are used with standby generators to automatically transfer power to the generator when utility power fails. Package includes our 100 AMP service entrance rated switch combining the disconnect and automatic transfer switch in one convenient enclosure.  Further battery, battery warmer are also included.

Monitoring

Eaton’s new generator monitoring system is the most efficient, cost effective method of viewing your backup power system’s status. Unlike wi-fi based programs, which ultimately fail in the event of an outage, homeowners are able to monitor the status of their generator on the go by using any smart phone, tablet or computer. Compatible with most brands, Eaton’s system is simple to install and easy to use. In addition, Eaton offers free monitoring for the first 12 months* as well as a 1-year limited warranty.

 Features and Benefits

Personalized web–based portal provides real time status information Generator is working properly

Reminds homeowner of schedule maintenance

Uninterruptible power during an outage unlike wi–fi based platforms

Most cost effective wireless monitoring system in the market

Quick installation

Easy to use

Multiple customizable messages for reduced troubleshooting time

Free monitoring service included for the first 12 months 1

1–year limited warranty

Compatible with most generator brands


Generac Motor

Maximizes engine “breathing” for increased fuel efficiency. Plateau-honed cylinder walls and plasma moly rings help engine run cooler, reducing oil consumption. Because heat is the primary cause of engine wear, the OHVI has a significantly longer life than competitive engines

• Rigid construction and added durability provide long engine life

• Assured smooth, quick start every time

• Superior lubrication to all vital bearings means better performance, less maintenance, and significantly longer engine life. Now featuring a 2-year/200-hour oil change interval

• Superior shutdown protection prevents catastrophic engine damage from low oil • Prevents damage due to overheating

• Allows for smaller, lightweight unit that operates 25% more efficiently than a revolving armature generator

• Produces a smooth output waveform for electronic equipment compatibility
• Maximizes motor starting capability
• Regulates the output voltage to ±2%, which prevents damaging voltage spikes

• Selects the operating mode for easy, at-a-glance status indication
• Weather-resistant interface allows smooth programming and operations for the user
• Constantly monitors utility voltage, set points 60% dropout, and 80% pickup of standard voltage • Prevents nuisance startups of the engine, adjustable 2 to 1500 seconds
• Ensures engine is ready to assume the load, set point approximately 5 seconds
• Allows engine to cool prior to shutdown, set point approximately 1 minute
• Operates engine to prevent oil seal drying and damage between power outages
• Maintains battery charge level to ensure starting
• Protects generator from overload
• Maintains constant 60 Hz frequency
• USB port allows programming updates for field adjustment vs. full replacement

• Ensures protection against nature’s elements. Hinged key locking roof panel for security. Lift-out front for easy access to all routine maintenance items. Electrostatically applied textured epoxy paint for added durability

• Quiet, critical grade muffler is mounted inside the unit to prevent injuries • Makes for an easy, eye-appealing installation
• Complies with local dB noise levels

• Easy installation using an Eaton Certified Contractor and extend your warranty to 5 years!

Copy & Paste Link to find an installer in your area:

http://www.eatoncanada.ca/EatonCA/ProductsSolutions/Electrical/YourBusiness/CertifiedContractors/FindanEatonCertifiedContractor/index.htm

View product
Air-cooled standby generator 22 kW Kit Quick shop
Air-cooled standby generator 22 kW Kit
Air-cooled standby generator 22 kW Kit
Air-cooled standby generator 22 kW Kit
Air-cooled standby generator 22 kW Kit
eaton

Air-cooled standby generator 22 kW Kit

$7,500.00 $8,000.00

Eaton's standby generators make it easy, affordable and worry-free, to supply reliable backup power for residential and light commercial applications. Whether you are home or away, they quietly protect your home and family, with an immediate, automatic, and reliable response to utility power failure, so power is never lost.

Kit Includes:

(1) 22 KW Eaton Generator

(1) Battery

(1) Battery & Oil Warmer

(1) 200 ATS with SE Rated Disconnect



Automatic Transfer Switches (ATS) with Disconnect and 3R rated!

Eaton's Automatic Transfer Switches (ATS) are used with standby generators to automatically transfer power to the generator when utility power fails. Package includes our 200 AMP service entrance rated switch combining the disconnect and automatic transfer switch in one convenient enclosure.  Further battery, battery warmer are also included.



 Features and Benefits

Personalized web–based portal provides real time status information Generator is working properly

Reminds homeowner of schedule maintenance

Uninterruptible power during an outage unlike wi–fi based platforms

Most cost effective wireless monitoring system in the market

Quick installation

Easy to use

Multiple customizable messages for reduced troubleshooting time

Free monitoring service included for the first 12 months 1

1–year limited warranty

Compatible with most generator brands


Generac Motor

Maximizes engine “breathing” for increased fuel efficiency. Plateau-honed cylinder walls and plasma moly rings help engine run cooler, reducing oil consumption. Because heat is the primary cause of engine wear, the OHVI has a significantly longer life than competitive engines

Rigid construction and added durability provide long engine life

Assured smooth, quick start every time

Superior lubrication to all vital bearings means better performance, less maintenance, and significantly longer engine life. Now featuring a 2-year/200-hour oil change interval

Superior shutdown protection prevents catastrophic engine damage from low oil Prevents damage due to overheating

Allows for smaller, lightweight unit that operates 25% more efficiently than a revolving armature generator

Produces a smooth output waveform for electronic equipment compatibility
Maximizes motor starting capability
Regulates the output voltage to ±2%, which prevents damaging voltage spikes

Selects the operating mode for easy, at-a-glance status indication
Weather-resistant interface allows smooth programming and operations for the user
Constantly monitors utility voltage, set points 60% dropout, and 80% pickup of standard voltage Prevents nuisance startups of the engine, adjustable 2 to 1500 seconds
Ensures engine is ready to assume the load, set point approximately 5 seconds
Allows engine to cool prior to shutdown, set point approximately 1 minute
Operates engine to prevent oil seal drying and damage between power outages
Maintains battery charge level to ensure starting
Protects generator from overload
Maintains constant 60 Hz frequency
USB port allows programming updates for field adjustment vs. full replacement

Ensures protection against nature’s elements. Hinged key locking roof panel for security. Lift-out front for easy access to all routine maintenance items. Electrostatically applied textured epoxy paint for added durability

Quiet, critical grade muffler is mounted inside the unit to prevent injuries Makes for an easy, eye-appealing installation
Complies with local dB noise levels

Easy installation using an Eaton Certified Contractor and extend your warranty to 5 years!

Copy & Paste Link to find an installer in your area:

http://www.eatoncanada.ca/EatonCA/ProductsSolutions/Electrical/YourBusiness/CertifiedContractors/FindanEatonCertifiedContractor/index.htm

View product
Canadian Service Entrance Rated ATS Quick shop
Canadian Service Entrance Rated ATS
Canadian Service Entrance Rated ATS
Canadian Service Entrance Rated ATS
eaton

Canadian Service Entrance Rated ATS

$995.00

Service Disconnect and ATS in One!

Our Service Entrance (SE) Rated switches combine the SE Disconnect and Automatic Transfer Switch (ATS) in one convenient enclosure.

They also feature LED position indicators for source availability, engine start signal and load management* capability!



EGSC100ASE

120/240

Whole House or Essential Loads

100

2

50/60

Yes

10,000

Mechanically Held Contactor

Type 3R (outdoor)

Basic (relay)



EGSC200ASE

120/240

Whole House or Essential Loads

200

2

50/60

Yes

10,000

Mechanically Held Contactor

Type 3R (outdoor)

Basic (relay)

View product
Eaton Metered, Service Entrance Rated Automatic Transfer Switch Quick shop
Eaton Metered, Service Entrance Rated Automatic Transfer Switch
Eaton Metered, Service Entrance Rated Automatic Transfer Switch
Eaton Metered, Service Entrance Rated Automatic Transfer Switch
Eaton Metered, Service Entrance Rated Automatic Transfer Switch
eaton

Eaton Metered, Service Entrance Rated Automatic Transfer Switch

$1,851.00

Features/benefits

  • Combined functionality in a single enclosure

  • Saves installation time and cost

  • Service entranced approved for Canada

  • 100 and 200A Models

  • Overhead or Underground service entrance

  • Type 3R indoor/outdoor enclosure

  • Accessory 15A Single Pole Circuit Breaker

    Applications

  • New or retrofit residential standby generator installa- tions

  • Farm or rural properties

    Everything in one box

    Traditionally, retrofitting a home to permit the connec- tion of a standby generator has meant considerable rework to the home’s electrical infrastructure. Often times this leads to the addition of multiple electrical enclosures and a network of conduit and cabling tying them together. The added complication of multiple enclosures increases the labour costs on installations. It also leaves the home owner with either a cluttered utility room or a less than attractive exterior installation. To solve some of these issues Eaton has developed its new metered, service entrance rated automatic trans- fer switch (ATS).

    Combined in a single enclosure and factory wired is
    a 200A meter socket, service entrance rated circuit breaker disconnect, and an ATS. The single enclosure assembly saves the installing contractor time and money while leaving the home owner with a more visu- ally appealing installation on the outside of their home.

  • Factory wired

  1. A traditional service entrance rated assembly would require the installation of a separately mounted meter socket, enclosed circuit breaker or fusible disconnect switch, and an ATS. Eaton provides all three devices
    in the one enclosure and factory wires them to carry the utility supply from the meter socket through to the ATS contactor assembly.

3R rated

Type 3R enclosure is construct- ed for either indoor or outdoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection
of the equipment inside the enclosure against ingress of solid foreign objects (falling dirt); to provide a degree of protection with respect to harmful effects on the equipment due to the

ingress of water (rain, sleet, snow); and that will be undam- aged by the external formation of ice on the enclosure.

Overhead/Underground Entrance

Two openings on the top of the enclosure provide for overhead service entrance hub mounting. Knockouts in the bottom of the enclosure and matching left and right hand wireways provide for bottom service entrance cabling. The unused wireway(s) can be removed providing additional space in the enclosure. Blanking plates are included to cover

the openings left behind by the removal of either wireway.

View product
Restore Power With Confidence of a 22kW Standby Generator Quick shop
Restore Power With Confidence of a 22kW Standby Generator
Restore Power With Confidence of a 22kW Standby Generator
Restore Power With Confidence of a 22kW Standby Generator
Restore Power With Confidence of a 22kW Standby Generator
eaton

Restore Power With Confidence of a 22kW Standby Generator

$6,500.00 $7,500.00

Eaton’s 22kW Standby Generators offer fully automatic operation and provide most homeowners with enough power for complete whole house comfort. These units all operate at ultra quiet 66 dB or less sound level. When paired with one of Eaton’s ATS’s you can get the most value of your purchase by managing your large loads.

Features:

User friendly digital controller

Electronic governor for consistent run speed

External GFCI outlet for running additional items during an outage

Flexible fuel line connector

Composite mounting pad

Natural gas or LP gas operation (field convertible)

Superior harmonics allow flawless operation of sensitive electronics such as computers

Best in class service network allows for piece of mind

100 ATS- Service Rated INCLUDED

BATTERY INCLUDED

WARMER INCLUDED

View product
Standby Generators Liquid Cooled 25kW Kit Quick shop
Standby Generators Liquid Cooled 25kW Kit
Standby Generators Liquid Cooled 25kW Kit
Standby Generators Liquid Cooled 25kW Kit
Standby Generators Liquid Cooled 25kW Kit
eaton

Standby Generators Liquid Cooled 25kW Kit

$12,562.00 $15,899.00

Gas Engine Generator Sets

Continuous Standby Power Rating:

EGEN25 (Steel) - 25 kW 60Hz

Naturally Aspirated

Gaseous Fueled

Meets 2009 EPA Emission Regulations



 Standard Equipment:

All input connections in one single area

High coolant temperature shutdown

Low oil pressure shutdown

Low coolant level automatic shutdown

Overspeed automatic shutdown

Crank timer

Exercise timer





 Features:

Innovative design and fully prototype tested

UL2200 Listed

Solid state frequency compensated voltage regulator

Dynamic and static battery charger

Sound attenuated acoustically designed enclosure

Quiet test for low noise level exercise

Acoustically designed engine cooling system

High flow low noise factory engineered exhaust system

State of the art digital control system with RSeries digital control panel

Watertight electrical connectors

Rodent proof construction

High efficiency, low distortion alternator

Vibration isolated from mounting base

Matching Eaton transfer switches engineered and tested to work as a system

All components easily accessible for maintenance

Electrostatically applied powder paint

Oil drain extension

Cool flow radiator

Closed coolant recovery system

UV/Ozone resistant hoses

Watertight state of the art electrical connectors

Mainline circuit breaker

Radiator drain extension

Battery charge alternator

2 Amp static battery charger

Battery cables



Specifications

Generator

Type

Synchronous

Rotor/Stator Insulation

Class F

Weight

895 lbs.

Total Harmonic Distortion

<5%

Telephone Interference Factor (Tif)

<50

Alternator Output Leads 3 Phase

4 wire

Bearings

Sealed Ball

Coupling

Flexible Disc

Excitation System

Direct

NOTE: Generator rating and performance in accordance with ISO8528-5, BS5514, SAE J1349, ISO3046, and DIN6271 standards.

Engine

Bore

3.15

Stroke

3.13

Compression Ratio

9.75:1

Intake Air System

Naturally Aspirated

Valve Seats

Replaceable

Lifter Type

Hydraulic

Oil Pump

Gear

Oil Filter

Full Flow Spin-On Cartridge

Crankcase Capacity

4 Quarts

Cooling System Type

Closed

Water Pump

Belt Driven

Fan Speed

2550

Fan Diameter

15 Inches

Fan Mode

Pusher

Governor

Type

Electronic

Frequency Regulation

Isochronous

Steady State Regulation

± 0.25%

Fuel System

Type

Natural gas, propane vapor

Carburetor

Down Draft

Secondary Fuel Regulator

Standard

Fuel Shut Off Solenoid

Standard

Operating Fuel Pressure

5” - 14” H2O

Voltage Regulator

Type

Electronic

Sensing

Single Phase

Regulation

± 1%

Features

V/F Adjustable, Adjustable Voltage and Gain LED Indicators

Electrical System

Battery Charge Alternator

12v 30 Amp

Static Battery Charger

2 Amp

Recommended Battery

Group 26, 525cca

System Voltage

12 Volts

View product
Standby Generators Liquid Cooled 45kW Quick shop
Standby Generators Liquid Cooled 45kW
Standby Generators Liquid Cooled 45kW
Standby Generators Liquid Cooled 45kW
Standby Generators Liquid Cooled 45kW
Standby Generators Liquid Cooled 45kW
eaton

Standby Generators Liquid Cooled 45kW

$19,899.00 $22,100.00

Standby Generators Liquid Cooled 45kW with Eaton commissioning and

200 Automatic transfer switch EGSX series

 Gaseous Fuelled

 Standard Equipment:

Eaton’s EGSX series residential automatic transfer switch product

line provides a safe and efficient means of transferring power

from utility to generator source. Its simplified relay-interface

system replaces complicated electronics, while increasing system

reliability and creating an intuitive design for faster installation

and troubleshooting.

All input connections in one single area

High coolant temperature shutdown

Low oil pressure shutdown

Low coolant level automatic shutdown

Overspeed automatic shutdown

Crank timer

Exercise timer

Oil drain extension

Cool flow radiator

Closed coolant recovery system

UV/Ozone resistant hoses

Watertight state of the art electrical connectors

Mainline circuit breaker

Radiator drain extension

Battery charge alternator

2 Amp static battery charger

Battery cables

Battery rack

Control Panel Features:

Seven Led Indicator Lights

System ready

Low fuel pressure

Low battery

Low oil pressure

High coolant temp/low coolant temp

Overspeed

Overcrank

Internal Functions:

3 position switch (auto, off and manual)

2 wire start for any transfer switch

Built-in 7 day exerciser

Selectable engine speed at exercise

Governor controller is built into the master control board

Temperature range -40 °C to 70 °C

Additional Functions:

Utility sensing

Delay on utility failure for engine start

Engine warm-up before transfer

Delay to retransfer to utility

Engine cooldown timer

Exerciser not set



Generator

Type

Synchronous

Rotor/Stator Insulation

Class H

Weight

1,414 lbs.

Total Harmonic Distortion

<5%

Telephone Interference Factor (Tif)

<50

Alternator Output Leads 3 Phase

4 wire

Bearings

Sealed Ball

Coupling

Flexible Disc

Excitation System

Direct

NOTE: Generator rating and performance in accordance with ISO8528-5, BS5514, SAE J1349, ISO3046, and DIN6271 standards.

Engine

Bore

3.41

Stroke

3.94

Compression Ratio

8.5:1

Intake Air System

Naturally Aspirated

Valve Seats

Precision Ground

Lifter Type

Overhead Valve Push Rod, Hydraulic

Oil Pump

Gear

Oil Filter

Full Flow Spin-On Cartridge

Crankcase Capacity

4 Quarts

Cooling System Type

Pressurized Closed

Water Pump

Belt Driven

Fan Speed

2060

Fan Diameter

22 Inches

Fan Mode

Pusher

Governor

Type

Electronic

Frequency Regulation

Isochronous

Steady State Regulation

± 0.25%

Fuel System

Type

Natural gas, propane vapor

Carburetor

Down Draft

Secondary Fuel Regulator

Standard

Fuel Shut Off Solenoid

Standard

Operating Fuel Pressure

5” - 14” H2O

Voltage Regulator

Type

Electronic

Sensing

Single Phase

Regulation

± 1%

Features

V/F Adjustable, Adjustable Voltage and Gain LED Indicators

Electrical System

Battery Charge Alternator

12v 30 Amp

Static Battery Charger

2 Amp

Recommended Battery

Group 26, 525cca

View product
