EVERVOLT™ HOME ENERGY STORAGE SYSTEM

Optimize your solar investment and create a more resilient energy future. With EverVolt you can store your

excess solar power for when you need it most or sell your surplus energy back to your local utility.

FEATURES

• Modular design with storage options from 11-17kWh to fit your needs*

• User friendly app to easily see your system’s performance

• Multiple operating modes

• Three main components for simple installation

• 10-year Panasonic warranty

What is EverVolt™?

•AC or DC coupled for new and existing solar systems

•11.4 or 17.1 kWh of energy storage –scalable to 102 kWh per home

•Lithium-ion battery technology using Panasonic’s 18650 battery cell used in many electric vehicles

•5.5 kW / 23A of continuous backup power per EverVolt

•Intelligent software to maximize your ROI

•Unique features including generator integration, high reliability, recyclability and faster availability shipping within 30 days.

Pricing Includes:

Freight to Destination

EverVoltSystem: Inverter, Battery Modules, Enclosure, Hardware Kit, App

When to choose a DC System?

New PV systems

When to choose a AC system?

Existing PV system with inverters that are under warranty and prefer to use AC modules.

DC System Sizing

PV array sizing is governed by the inverter PV input

•1 x EverVolt = 6.5 kW DC

•2 x EverVolt = 13 kW DC

•3 x EverVolt = 19.5 kW DC

•Stacking systems to increase backed up load capability

•2 x EverVolt = 9 kW / 46A

•3 x EverVolt = 13 kW / 69A

Generator Integration

An external generator can be used to power backed up loads when batteries reach 10% SoC

•Generator auto-start capability for electric start models

•Compatible with generators that deliver clean 240 VAC at 60 Hz. Single-phase and three-phase generators are not compatible.

•Generator sizing

•Should be sized to provide enough power and current for all loads.

•Minimum recommended size is 7.5 kW.

What can I backup during a power outage with oneEverVolt system?

•Refrigerator

•Lights

•Garage door

•Internet

•Cell phones / tablets / computers

•Coffee maker

What can I backup during a power outage with 2-3EverVolt systems?

Basic loads as per above plus:

•Small A/C units

•Small well / pool pumps

•Electric Vehicles (low charge setting)

•Additional heating elements (electric stove, toaster, espresso machine, etc.)

Other costs such as 3rd party electrician Installation Costs to be aware of (supplied by other) in addition to solar and batteries:

•Permitting and plans set: $700-1000

•Additional Materials e.g. Essential loads panel, conduit, cabling: $600

•Installation 1 day for two people: $1500

•Total: $3,100

•Additional costs can include: length of wire run, hidden conduit, difficult in pulling loads to backed up loads panel

Manual Transfer Switches / Generator Panels • Main utility and emergency (generator) breaker factory installed. • Available in 30 and 60 ampere design. • Utility breaker and generator breakers are mechanically interlocked to protect equipment and personnel by preventing dangerous dualsource feeding. • Critical loads permanently connected to allow for quick and convenient switching from utility power to standby generator power. • Designed for switched neutral applications. Can be reconfigured in field for non-switched neutral applications. • Sturdy and reliable 125A rated aluminum bus design. • Type BR/DNPL branch breakers sold separately. • Ideal for new and retrofit installations. • EEMAC 1 indoor enclosure design.

CBRPL112G3

120/240V 621037004870 125A 30A Yes Yes EEMAC 1 16.75" x 14.38" x 3.88"

CBRPL112G6

120/240V 621037004887 125A 60A Yes Yes EEMAC 1 16.75" x 14.38" x 3.88

A perfect fit for any home, the 20kW₁ Fortress standby generator powers all of a home's electrical needs easily and automatically. Keep your family safe, comfortable and free from the stress that comes with power outages.  INCLUDES BATTERY, WARMER, COMMISSION, 6 YEAR WARRANTY, APP BASED & SERVICE RATED 200ATS.

993cc

Displacement

3600

RPM

6 Year

Limited Warranty

200ATS

Service Rated Auto Transfer Switch

WIFI

APP based Standby Generator control in your hands

AmplifyTM Power Management Transfer Switch Bundle

Where would you be without a constant flow of electrical power? We often take for granted that power will always be around when we need it. In reality, power failures are common, and when the power goes out, your business suffers. Power failures are unpredictable. They can occur at any time and for any number of reasons — a bolt of lightning, a power surge, a blackout, an accident or even equipment failure. They come without warning and often at the most inconvenient times. It’s for this reason that many businesses and other entities have invested in emergency power backup systems. Typically, the system consists of an engine generator and an automatic transfer switch (ATS) that transfers the load from the utility to the generator. An ATS with built-in control logic monitors your normal power supply and senses interruptions and unacceptable abnormalities. When the utility power fails, the ATS automatically starts the engine generator and transfers the load after the generator has reached proper voltage and frequency. This happens in a matter of seconds after the power failure occurs. When the utility power has been restored, the ATS will automatically switch the load back and, after a time delay, shut down the engine generator. With an ATS, you are protected 24 hours a day, seven days a week.

Service Rated ATS requires less components, installs indoor or outdoor, has a built in disconnect and therefore makes it easily accessible to service your generator!

• Automatically transfers power to your generator during an outage

• Automatically transfers power to your generator during an outage

 Kohler is pleased to announce the release of an expanded offering in our service entrance rated residential transfer switches for our Standby Generators! These NEW products add to Kohler comprehensive line of residential transfer switches.  With the electrical contractor and homeowner in mind, Kohler has designed and manufactured an ALL IN ONE solution to meet CEC requirements for complete home Standby Generator backup.

Introducing the industry first 400 amp service entrance rated automatic transfer switch, featuring LED position indicators. Advance load management, and engine start options.
