LSXR10

912401453203

No stock

10 weeks

The LSXR Family of fixture mount occupancy sensors provides reliable and versatile solutions for commercial and industrial lighting control applications. All LSXR Family sensors utilize passive infrared (PIR) detection and feature interchangeable lenses, providing flexibility for multiple mounting height and coverage pattern requirements. All LSXR Family sensors utilize 100% digital Passive Infrared (PIR) detection and power from / switch line voltage. Available options include dual relays, HVOLT powering, and an integrated switching / dimming photocell.
Features:

• Four interchangeable lenses: high mount 360º; low mount 360º; high mount aisleway; and small motion 360º
• Integrated mounting bracket drops lens down 3” from chase nipple (no bracket accessory required)
• 100% digital PIR detection - provides excellent RF immunity
• No PIR field calibration or sensitivity adjustments required
• Single or dual relay versions - designed with robust protection from the harsh switching requirements of T5 fluorescent and LED loads
• Powers from single or two-phase line connections
• Reversible hot and load wires - eliminates backwards wiring
• Photocell and 0-10 VDC dimming options
• Digital push-button programming (no tools or analog adjustments required)

2 – *600

MCM * Nominal Capacity for certain cable type only

• Produces a wide, focused light at an angle
• Designed for illuminating yards, walls and espaliers
• Drive-over

27K-50K

Selectable

Features

LUNA
3.5" LUNA LED 2-Light Linear Gimbal Color
Selectable Recessed Fixture
Recessed Downlighting

Body
Durable airtight aluminum body with
adjustable gimbal. Includes anodized
blue heat sink to provide maximum
airflow for the LED light source.

LED Characteristics
This general application light fixture
features 18 watt LED module that
maintains uniform intensity. with a typical CRI of
90. On-fixture color selectable switch
allows switching between 2700 K,
3000 K, 3500 K, 4000 K and 5000 K
color temperatures.

Dimming
100%-10% dimming capability. This
fixture is compatible with industry
standard forward-phase / reverse-phase
and TRIAC/ELV dimmers (contact
factory for list of compatible dimmers).

Beam Spread
The fixture lens provides 38° beam
spread.

Mounting
Includes four spring loaded clips to
attached to any ceiling material.

LED Driver
Extruded aluminum hardwire box with
two 210mA dimmable class II electronic
LED drivers with 100-135V AC input.
Includes an 18" FT6 rated cable with
DC 2.1 connector between driver and
fixture approved for use in plenums and
suspended ceilings.

“Quick connect” push-in terminals for
fast and easy wiring.

Operating Temperature
-20°C~40°C (-4°F~104°F)

Environment
• Suitable for wet locations.
• Approved for direct contact with
insulation.
• Airtight

Code examples: Specify color in notes upon ordering

SC1 = 1 Gang

SC2 = 2 Gang

SC3 = 3 Gang

SC4 = 4 Gang

SC5 = 5 Gang

SC6 = 6 Gang

SC7 = 7 Gang
