Compact, low profile design with low glare optics.

Post Top LED, Neutral White, Generation 1, tenon mount, Type 3, Field Adjustable Wattage Selector, setting 4 (53W) HV3 multi volt 120v-347v

24FT/LED/STRING LIGHT/120V

LED 24 foot LED String light - Includes 12 One Watt LED filament bulbs

T8 - TYPE A + B 5 CCT SELECTABLE LED Linear Tubes

Model Number: T8/12W/80/5CCT/36/AB/120-347/STD/SMX

Tape

LED-TP1-12 is an indoor 12" (305mm) LED tape light. It provides ample illumination for effective residential, retail and light commercial displays. LED-TP1-12 is ideal for decoration of ceilings, wall or contour marking, backlit signs, under-cabinet, in-cabinet, toe kicks, and task lighting. It can be linked for continuous uninterrupted lighting. For indoor use only (dry location).  Low wattage ensure long lasting stick.

Low Voltage Splice Kit

LED-TP-BL-EL Flexible LED tape extension leads, for use with single colour LED indoor tape light, 24V connecting tape to low voltage wire for multiple new connection points.

40W Driver provides up to 30' runs (requires MAPRO non wifi or ELV+ caseta wifi dimmer options)

96W Driver provides up to 30' x 2 parallel runs (requires RRDF6AN dimmer)

The Hi-lume Premier 0.1% Constant Voltage Driver (L3D0) is a high-performance LED driver capable of controlling up to 96 W of 24 V- constant voltage loads. This driver provides smooth and continuous dimming down to 0.1% low-end. It is ideal for use with strip lighting in applications such as coves, under or over cabinet lighting and pathway lighting. The driver is UL® Listed with an integrated wiring compartment and can be mounted up to 150 ft (45 m) away from the load.

EXTRUSION

65867 series EXTRUSION / 210 / RECESSED /8' /ALUM /STD 66343 with frosted lens

210 Recessed

Silver 8' length

1 1/32 width

7/16 inches height

Compatible Dimmers

Radio Ra

3-Wire Fluorescent/LED (120–277 V~) RRD-F6AN-DV-WH 6 A Neutral Wire Dimmer for 96W Driver

Caseta ELV+ PD5NE

• Works with Alexa, Google Assistant, and more (Smart Bridge required)

• Compatible with dimmable LED, ELV, MLV, incandescent and halogen bulbs

• Easily replaces existing switch and installs in as little as 15 minutes (neutral wire is required) works on 40W Driver

Maestro PRO LED+

Dimmer Phase-selectable dimmer for LED, ELV, MLV and incandescent lamp loads.

LED Wrap

Most popular and readily available for your everyday lighting needs

A low-profile, linear and narrow wraparound with decorative end-caps and a frosted diffuser providing widespread, uniform illumination. Ideal for many applications including corridors, kitchens, breakrooms, utility work areas and stairways.

Specs:

120V/277V

3000K/ 3500K/ 4000K

4' LED Wrap

0-10V Dim

4000 Lumens

34W LED

Double Bar Rebate Lock Key

• Keyswitch Controller
• 35’ winch cable
• 1650 watt light wattage capacity
• 110 volt
• Mounts directly above fixture (at least 3’ vertical access space recommended)
• 14” wide x 19” long x 9” high (mounted on two 36” channel struts)
• Plastic dust cover
• Romex wire
• 50’ Controller wire
• UL Listed

Power Packs are the heart of the low voltage sensor system. The PP20 transforms 120, 240 or 277 volts to Class II 15 VDC to power the remote sensors. Utilizing our patented relay circuit protection, the PP20 also switches the lighting load on and off. This method has been tested to over 400,000 cycles at rated load!

Although Plenum Rated, the elongated mounting nipple allows for the PP20 to be mounted either directly through a 1/2 inch knockout in a junction box or to be located inside an adjacent box for specific local code requirements. Up to 14 sensors may be connected to one PP20. Multi-circuit control can be handled by multiple PP20s or via 2-pole power packs (PP20 2P) and slave packs (SP20). PP20s can be wired continuously hot (line side) or on the switch leg (load side) without nuisance delays upon turn on.
Features:

• Dual voltage transformer
• Self-contained relay
• Patented relay contact protection (tested to over 400K cycles)
• Powers up to 14 sensors

Product Details
